Marca :
Bently NevadaNumero parte :
330880-28-15-042-00-02Il peso :
1.45kgDimensione :
33x9x9cmPaese d'origine :
USACodice SA :
8537101190Descrizione :
PROXPAC XL Proximity Transducer
|
Bently Nevada 330880-28-15-042-00-02 PROXPAC XL Proximity Transducer |
|
330880-AA-BB-CCC-DD-EE: A: Probe and Approvals Option: 28 3300 XL 8 mm probe with Multiple Approvals B: Standoff Adapter Option: 15 1.5 in (38 mm) C: Probe Penetration Option: 042 4.2 in D: Fittings Option: 00 No fittings; two plugs and two washers E: Mounting Thread Option: 02 3/4-14 NPT
|
|
Get Best Price - Please Contact Frida |
|
|
Phone/Whatsapp: +86 15359408275 |
|
|
Email: sales5@mooreplc.com |
|
|
Bently Nevada 330880-28-15-042-00-02 FAQ |
||
|
What is the primary benefit of using a PROXPAC XL system instead of standard proximity probes?
The PROXPAC XL eliminates the fragile connection point between the probe pigtail and the extension cable
What are the electrical parameters and scale factor? Because it contains standard 3300 XL 8 mm electronics, it adheres to standard system specs: · Scale Factor / Sensitivity: 200 mV/mil (7.87 V/mm). · Linear Range: 80 mils (2.0 mm). · Supply Voltage Required: -17.5 VDC to -26 VDC
Product Series: Bently Nevada PROXPAC XL Proximity Transducer Assembly
The design of the PROXPAC XL Proximity Transducer Assembly is similar to our 31000/32000 Proximity Probe Housing Assemblies. The assembly offers the same advantages and features as the 31000 and 32000 housings for accessing and externally adjusting proximity probes. However, the housing cover of the PROXPAC XL Assembly also contains its own 3300 XL Proximitor sensor. This design makes the PROXPAC XL Assembly a completely self-contained proximity probe system, and eliminates the need for an extension cable between the probe and its associated Proximitor sensor. It also eliminates the need for a separate Proximitor housing, as the field wiring connects directly between the monitors and PROXPAC XL Assemblies.
|
||
|
