DI561 is an ABB S500-eCo digital input module for centralized AC500/AC500-eCo CPU expansion or decentralized S500 communication-interface expansion. It provides eight 24 V DC / 24 V AC digital inputs in one galvanically isolated group.
8 DIGITAL INPUTS · 24 V DC / 24 V AC
Click “+” to expand more specifications.
DI561 is an ABB S500-eCo digital input module. It provides eight 24 V DC or 24 V AC inputs and can serve as centralized I/O expansion for AC500/AC500-eCo CPUs or decentralized expansion through supported S500 communication-interface modules.
DI561 provides eight digital inputs, I0 through I7, in one group for 24 V DC or 24 V AC signals. ABB describes the input group as module-wise galvanically isolated, so channel count and field-voltage type must match the application.
DI561 is listed by ABB as Active under order code 1TNE968902R2101. That status does not make a different S500-eCo module a direct replacement; verify channel count, voltage, terminal block, wiring, software configuration and mechanical compatibility before changing hardware.
DI561 requires one 9-pole terminal block and must be installed with power removed because ABB does not support hot swap for this module. Confirm the CPU or communication interface, input wiring, 24 V AC/DC signal type, terminal assignment and Automation Builder configuration.
Share the complete order number and application details for compatibility, availability and lead-time checking.
Official ABB documentation for DI561 digital input module, order code 1TNE968902R2101.
ABB data sheet 3ADR010048, revision 10, identifies DI561 as an active 8-channel 24 V DC / 24 V AC digital input module.
VIEW OFFICIAL PDF ↗
Model: DI561
Order code: 1TNE968902R2101
Lifecycle: Active
Date: 2023-08-05
Only ABB manufacturer documentation is linked on this page.
ABB is the brand; S500-eCo is the I/O family; DI561 is the 8-channel digital input module for centralized AC500/AC500-eCo expansion or decentralized S500 communication-interface expansion.
Use as centralized or decentralized I/O only with a supported ABB CPU or communication interface.
Verify the CPU or communication interface, 9-pole terminal block, input wiring and software configuration.
ABB lists DI561 as Active in the official ordering data.
