Bently Nevada 330881-16-10-110-06-02 Proximity Transducer, Metric

Parameter

Specification

Model Number

330881-16-10-110-06-02

Brand / Series

Bently Nevada PROXPAC XL (Metric Configuration)

System Type

Integrated housing with 3300 XL Proximitor® sensor + 3300 XL 8 mm probe

Probe Type

3300 XL 8 mm probe with 1-meter fixed triaxial cable

Probe & Approvals Option

16 – 3300 XL 8 mm probe without approvals

Standoff Adapter (B Dimension)

10 – 100 mm (minimum: 40 mm / maximum: 200 mm, ordered in 10 mm increments)

Probe Penetration (C Dimension)

110 – 110 mm (minimum: 25 mm / maximum: 760 mm, ordered in 1 mm increments)

Fittings Option

06 – One 3/4-14 NPT fitting + one 3/4-14 NPT to 1/2-14 NPT SST reducer + two plugs

Mounting Thread Option

02 – 3/4-14 NPT (required when ordering Standoff Adapter)

Linear Range

2 mm (80 mils)

Incremental Scale Factor (ISF)

7.87 V/mm (200 mV/mil) ±5%

Recommended Gap Setting

1.27 mm (50 mils)

Power Supply

-17.5 Vdc to -26 Vdc (without barriers) / -23 Vdc to -26 Vdc (with barriers)

Field Wiring Max Length

305 m (1,000 ft) – 3-conductor shielded triax cable (16–24 AWG)

Enclosure Rating

Type 4X, IP66 (BASEEFA T07/0709)

Operating Temp (Housing)

-52°C to +100°C (-62°F to +212°F)

Operating Temp (Probe Tip)

-52°C to +177°C (-62°F to +351°F)

What is the difference between 330800 (English) and 330881 (Metric) models?

The 330881 series is the metric version of the PROXPAC XL. While both use the same probe and Proximitor® technology, the 330881 specifies standoff adapter (B dimension) and probe penetration (C dimension) in millimeters rather than inches. The selection of mounting thread options also differs to accommodate metric or NPT requirements.

Does this model include hazardous area approvals?

No. The "16" option indicates a 3300 XL 8 mm probe without approvals. If hazardous area certifications (ATEX, IECEx, cNRTLus) are required, you would need to select the "28" option (Multiple Approvals) instead. This non-approved configuration is suitable for general-purpose or non-hazardous installations.

What is the effective probe penetration after installation?

With a standoff adapter (B = 100 mm) and probe penetration (C = 110 mm), the total "B + C" dimension represents the mid-setting distance between the mounting surface and the target surface. The threaded sleeve allows ±12.7 mm (±0.5 in) adjustment from this point. If the combined dimension exceeds 305 mm (12 in), additional sleeve support near the probe is recommended to avoid resonance effects.

What is the maximum field wiring length for this assembly?

You can use up to 305 meters (1,000 feet) of 3-conductor shielded triax cable (16–24 AWG) between the PROXPAC XL assembly and your monitoring system.

What conduit fittings are included with the “06” option?

The Fittings Option 06 includes:
One 3/4-14 NPT fitting
One 3/4-14 NPT to 1/2-14 NPT stainless steel reducer
Two blanking plugs
This configuration provides flexibility for connecting standard 3/4-inch conduit or reducing to 1/2-inch NPT where smaller conduit entries are required.
