Product Overview

The Bently Nevada 9200-09-01-06-00 is a two-wire moving-coil Seismoprobe Velocity Transducer for measuring absolute bearing-housing, casing, and structural vibration. This configuration combines a 15 Hz minimum operating frequency, a top-mounted connector without an integral cable, and an isolated circular 1/4-20 UNC mounting base. Its output voltage is directly proportional to vibration velocity.

Model Number Breakdown

Official ordering format: 9200-AA-BB-CC-DD
9200: Bently Nevada two-wire Seismoprobe Velocity Transducer.
AA – 09: 0° ±180° mounting orientation with a 15 Hz (900 cpm) minimum operating frequency.
BB – 01: Top-mounted connector; no integral cable.
CC – 06: Isolated circular mounting base with a 1/4-20 UNC stud.
DD – 00: No agency approvals.

Technical Information

Parameter	Value
Manufacturer	Bently Nevada
Product Type	Two-wire moving-coil Seismoprobe Velocity Transducer
Mounting Orientation	0° ±180°
Minimum Operating Frequency	15 Hz (900 cpm)
Connector / Cable Option	Top-mounted connector; no integral cable
Mounting Base	Isolated circular base with 1/4-20 UNC stud
Sensitivity	20 mV/mm/s (500 mV/in/s), ±5%
Frequency Response	15 to 1,000 Hz; +0, -3 dB typical
Dynamic Operating Range	2.54 mm (0.100 in) peak-to-peak maximum displacement
Velocity Range	25 mm/s (1 in/s) at 100 Hz with a 10 kΩ load
Coil Resistance	1.25 kΩ ±5%
Operating and Storage Temperature	-29°C to +121°C (-20°F to +250°F)
Relative Humidity	Up to 95%, non-condensing

Industries Served

• Power generation facilities
• Oil and gas processing plants
• Chemical and petrochemical operations
• Pulp and paper production lines
• Water and wastewater facilities
• General industrial manufacturing

Application Areas

-Continuous casing-vibration monitoring on rotating machinery
-Periodic vibration checks with diagnostic instruments
-Bearing-housing vibration measurement
-Machine-structure vibration measurement
-Portable vibration measurement applications

Key Highlights

Key Highlight	Details
Absolute Vibration Measurement	Measures bearing-housing, casing, and structural vibration relative to free space.
Direct Velocity Output	Produces an output voltage directly proportional to vibration velocity.
15 Hz Configuration	The 09 option provides a 15 Hz minimum operating frequency.
Broad Orientation Range	Supports a 0° ±180° mounting orientation.
Top-Mounted Connector	The 01 option uses a top-mounted connector without an integral cable.
Isolated Circular Base	The 06 option provides an isolated circular base with a 1/4-20 UNC stud.

Frequently Asked Questions

1. What does the Bently Nevada 9200-09-01-06-00 measure?
It measures absolute bearing-housing, casing, and structural vibration and provides an output proportional to vibration velocity.

2. What is the minimum operating frequency of this configuration?
The 09 option provides a 15 Hz, or 900 cpm, minimum operating frequency.

3. Does this model include an integral cable?
No. The 01 connector option specifies a top-mounted connector without an integral cable.

4. What mounting base is provided by the 06 option?
The 06 option specifies an isolated circular mounting base with a 1/4-20 UNC stud.

5. Can the 9200 be used for continuous vibration monitoring?
Yes. The 9200 family is suitable for continuous monitoring and periodic diagnostic measurements.
