Honeywell CC-INWE01 Network Expansion Module

★Contact for Quoting★

Sales Manager: Frida
Phone: +86 15359408275
Email: sales5@mooreplc.com
Address: Siming District, Xiamen, Fujian, China

Discover This Product

Specification:

Description: Control Network Module - Expansion Module
Product Line: Honeywell Control Network Module (CNM)
Form Factor: Modular expansion unit
Mounting Options: CCA (Carrier Channel Assembly) or DIN rail mounting (when used with the complete CNM assembly)
Operating Temperature Range: -40 to +70 °C
Humidity Range: 10% to 90% RH (non-condensing)
Port Configuration:
4 combo ports (Fiber/Copper) @ 10/100/1000 Mbps
4 Ethernet ports @ 10/100 Mbps
Total Downlink Ports Provided by Expansion Module: 8 ports
SFP Types Supported: Single Mode (up to 15 km), Multi-Mode (up to 2 km)
Data Rate: Up to 1 Gbps on combo ports, 100 Mbps on Ethernet ports

FAQ:

1.What is the main purpose of the CNM system (Main + Expansion)?
The CNM provides a rugged, "zero-configuration," and cyber-secure network switch solution specifically designed for integrating Honeywell's Level 1 control devices (like Safety I/O, C300 controllers, IO HIVE) into the Experion PKS system over Honeywell's Fault Tolerant Ethernet (FTE) and Safety networks.
2.What is Honeywell Series C I/O?
Series C I/O family is equipped with a unique, patented heat channeling form factor and its components can be implemented in a redundant fashion to provide a solution with no single point of failure. Its highly flexible modules can be placed both local and remote to the control processor.
3.How many and what type of ports does the CC-INWE01 Expansion Module add?
The expansion module provides 8 additional downlink ports:
4 Combo Ports: These are 10/100/1000 Mbps ports that can accept either copper (RJ-45) or fiber optic (via SFP) connections.
4 Ethernet Ports: These are dedicated 10/100 Mbps copper (RJ-45) ports.
