The 6ES7288-2DR32-0AA0 is a Siemens SIMATIC S7-200 SMART EM DR32 expansion module combining sixteen 24 V DC digital inputs with sixteen dry-contact relay outputs rated 2 A per point.
Digital Input/Relay Output Expansion Module
Click “+” to expand more specifications.
6ES7288-2DR32-0AA0 adds 16 digital inputs and 16 relay outputs, providing 32 mixed field points from one expansion module.
6ES7288-2DR32-0AA0 accepts 24 V DC sink/source inputs for proximity sensors, limit switches and dry contacts, with about 4 mA nominal input current per active channel.
6ES7288-2DR32-0AA0 dry contacts can switch external circuits in the range of 5–30 V DC or 5–250 V AC, subject to the real load category and protection.
6ES7288-2DR32-0AA0 is rated up to 2 A per relay point and 8 A per common. Divide high-inrush loads among commons and protect each field supply.
6ES7288-2DR32-0AA0 measures 70 × 100 × 81 mm, weighs about 295 g and has approximately 10 W power consumption.
6ES7288-2DR32-0AA0 can switch suitable coils when steady current and inrush are within rating; use a flyback diode, RC network or manufacturer-approved suppressor for inductive loads.
For 6ES7288-2DR32-0AA0, provide the CPU order number, input sensor wiring, every load voltage and inrush current, common-group plan, quantity and destination.
Share the complete order number and application details for compatibility, availability and lead-time checking.
Official Siemens documentation for the SIMATIC S7-200 SMART CPU CR60s.
Siemens technical datasheet for 6ES7288-1CR60-0AA1, including electrical, I/O, memory, communication, environmental, dimension and weight data.
OFFICIAL DATASHEETSend the complete model, quantity, and your technical or purchasing question.
Technical statements on this product page are based on publicly available official Siemens manufacturer documentation.
Siemens is the brand; SIMATIC S7-200 SMART is the PLC family; and 6ES7288-1CR60-0AA1 is the CPU CR60s AC/DC/Relay model with onboard I/O and communication.
CPU CR60s executes the user program and manages its onboard 36 digital inputs and 24 relay outputs.
STEP 7 Micro/WIN SMART is used to configure, program and commission the S7-200 SMART CPU.
The integrated RS485 port supports PPI, Modbus RTU, USS and free-port communication.
A clear workflow for sourcing, verification, shipment preparation, delivery and product assurance.
Include the complete part number, quantity and delivery destination.
