VIBRO METER TQ412 S3960 111-412-000-013 Reverse Mount

BRAND/ MANUFACTURER:

PART NUMBER

CONDITION:

COUNTRY OF ORIGIN

VIBRO METER

TQ412 S3960 111-412-000-013

Brand New Factory Sealed - Original

Name：Frida

Email：sales5@mooreplc.com

Whatsapp：+86 15359408275

Welcome to Inquire

The TQ412 form a proximity measurement system, from Meggitt’s vibro-meter® product line. This proximity measurement system allows contactless measurement of the relative displacement of moving machine elements.

The TQ412 version is intended for reverse-mount applications. Both the TQ402 and TQ412 have an integral coaxial cable, terminated with a self-locking miniature coaxial connector.

The TQ412 transducers can be matched with a single EA402 extension cable to effectively lengthen the front-end. Optional housings, junction boxes and interconnection protectors are available for the mechanical and environmental protection of the connection between the integral and extension cables.

Transducer : −40 to +180°C with drift <5% (operating). +180 to +220°C with drift >5% (short-term survival).

Transducer and cable : −40 to +195°C if used in an Ex Zone

Cable, connector and optional protection : −40 to +200°C

Vibration(according to IEC 60068-2-26) : 5 g peak between 10 and 500 Hz

Shock acceleration(according to IEC 60068-2-27) : 15 g peak (half sine-wave, 11 ms duration)
