GE MARK VIE · PCAA CORE ANALOG TERMINATION

IS400TCASH1A

IS400TCASH1A is a GE Mark VIe TCAS terminal board for the PCAA core analog assembly. It provides 120 field terminal positions, bulk 28 V dc power connections and two 68-pin TCAT cable connectors, routing signals to the BCAA and BCAB analog boards.

PRODUCT TYPECORE ANALOG TERMINAL BOARD
PLATFORMMark VIe
FIELD TERMINALS120 positions
TCAT INTERFACE2 × 68-pin
MANUFACTURERGE
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Informarsi ora
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
GE ● CORE ANALOG TERMINAL BOARD
MARK VIE

IS400TCASH1A

CORE ANALOG TERMINAL BOARD

MARK VIE · TCAS · PCAA CORE ANALOG FIELD INTERFACE

MODULE ROLE
IS400TCASH1A is the TCAS core analog terminal board used within the PCAA assembly.
LONG DESCRIPTION
IS400TCASH1A provides field wiring terminations, 28 V dc control-power connections and the P1/P2 TCAT cable interfaces. Signal paths connect the terminal arrangement to the BCAA and BCAB analog boards.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
ORDER NUMBER BREAKDOWN

How the IS400TCASH1A Reference Is Structured

IS
Issuing organizationGE, Salem, Virginia
4
Substance codeRoHS designation
00
Assembly levelPrinted wiring assembly
TCAS
Board functionCore analog signal termination
H
Technology codeSurface-mount components included
1
Board groupTCAS hardware group 1
A
Compatibility versionBackward-compatibility version A
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

GE Mark VIe ↗
IS400TCASH1A CORE ANALOG TERMINAL BOARD

Engineering data at a glance

Click “+” to expand more specifications.

FIELD TERMINALS120 positions
CONTROL POWER28 V dc
TCAT CONNECTORS2 × 68-pin
SYSTEM ROLEPCAA termination
120 field terminal positions, 28 V dc power connections and two 68-pin TCAT cable interfaces.
Core analog board relationship Board IS400TCASH1A provides the TCAS field interface. BCAA and BCAB perform the associated analog processing within the PCAA assembly.
GENERAL INFORMATION −
BrandGE
Part numberIS400TCASH1A
Product typeCore Analog Terminal Board
Field terminals120 positions
Control powerBulk 28 V dc
Associated assemblyPCAA core analog module
POWER & CABLE CONNECTIONS ＋
P5Bulk 28 V dc input
P4Power connection to JGPA
P1 and P2Two 68-pin TCAT cable connectors
SIGNAL ROUTING ＋
Internal processing interfaceBCAA and BCAB analog boards
Thermocouple terminations25 input signal pairs
LVDT excitationSix excitation signal pairs
Servo connectionsSix servo-coil output circuits
TCAT connectionExternal core-analog terminal-board cables
PCAA FIELD INTERFACE ＋
Board role: TCAS provides the PCAA assembly with field wiring terminals, power connections and signal routing. The processor and analog acquisition circuitry reside on the associated PCAA circuit boards.
Source: GEZ-S2029, PCAA module component table; GEH-6721T Volume II, PCAA and TCAS terminal-board sections; GE Vernova Intertek ATM 105977928DAL-001, 27 March 2026.
FAQ

Questions Buyers Ask Most

What is the role of IS400TCASH1A?＋

IS400TCASH1A is the TCAS field-termination and signal-routing board within the PCAA core analog assembly.

How many field terminal positions are on IS400TCASH1A?＋

IS400TCASH1A provides the 120-position field termination arrangement used by the PCAA assembly.

Where does control power enter IS400TCASH1A?＋

IS400TCASH1A receives bulk 28 V dc control power through P5 and provides a power connection to the adjacent JGPA board through P4.

How does IS400TCASH1A connect to TCAT?＋

IS400TCASH1A provides P1 and P2 68-pin cable connectors for the TCAT core analog terminal board.

Which internal analog boards interface with IS400TCASH1A?＋

IS400TCASH1A routes signals to the BCAA and BCAB boards inside the PCAA assembly.

Does IS400TCASH1A include the complete PCAA processor assembly?＋

IS400TCASH1A identifies the TCAS terminal board. The complete PCAA assembly also contains its processor and application I/O boards.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Product Information for
IS400TCASH1A

Official manufacturer-manual PDF status for GE IS400TCASH1A.

Official manual PDF status

A direct manufacturer-hosted instruction-manual PDF covering IS400TCASH1A was not located in the public documentation checked. For the applicable manual and product documentation, please contact Product Specialist Frida.

CONTACT FRIDA

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

GEZ-S2029, PCAA module component table; GEH-6721T Volume II, PCAA and TCAS terminal-board sections; GE Vernova Intertek ATM 105977928DAL-001, 27 March 2026.

GE MARK VIE CORE-ANALOG RELATIONSHIP

How IS400TCASH1A Connects the PCAA Field Interface

GE is the manufacturer brand; GE Mark VIe is the product family; and IS400TCASH1A is the core analog terminal board for PCAA field termination and analog-signal routing.

GE · BRAND
GE Mark VIeCore Analog Terminal Board
SYSTEM ROLE

Core Analog Terminal Board

Connects field wiring, TCAT cables and control power to the PCAA assembly.

MODULE / CONFIGURATION

120 terminals · 2 × 68-pin connectors

P5 accepts 28 V dc bulk power; P4 connects power to JGPA.

TCAS, TCAT & ANALOG-BOARD INTERFACE

IS400TCASH1A · Core Analog Terminal Board

P1 and P2 connect TCAT cables; internal connectors route signals to BCAA and BCAB.

System relationship: Field signals enter through TCAS terminals or TCAT cables. TCAS routes them to the analog boards in the PCAA assembly, whose processor exchanges the acquired data with the controller.
APPLICATION AREAS

Application map for IS400TCASH1A

Core Analog Field WiringTerminate turbine analog signal circuits
TCAT Cable RoutingConnect external analog terminal-board cables
PCAA CORE ANALOG TERMINATION IS400TCASH1A IS400TCASH1A · Core Analog Terminal Board
Control Power ConnectionsRoute bulk 28 V dc within the assembly
PCAA Internal IntegrationInterface with BCAA and BCAB boards
