Siemens 6ES7135-6HB00-0DA1 Analog Output Module

Contact Us

Email:sales5@mooreplc.com
Phone/Whatsapp/Wechat:+86 15359408275

Description

SIMATIC ET 200SP, analog input module, AI 4XU/I 2-wire Standard, suitable for BU type A0, A1, Color code CC03, Module diagnostics, 16 bit, +/-0.3%. 6ES7134-6HD00-0BA1 has been discontinued. Its direct replacement model is 6ES7134-6HD01-0BA1.

Specifications

Number of Analog Outputs:2
Firmware Version:V2.0.1
Usable BaseUnits:BU type A0, A1
Supply Voltage (Rated) : 24 V DC
Supply Voltage Range:19.2 V to 28.8 V DC
Current Consumption:45 mA (no load)
Power Loss, typ.:0.9 W
Cycle Time (all channels), min. :125 μs
Load Resistance:Voltage output: min. 2 kΩ; Current output: max. 500 Ω
Cable Length, shielded, max.:1000 m (200 m for voltage output)

Application

High-Speed Control Loops: The module is designed for applications requiring fast, time-synchronized signal output. Its support for isochronous mode with a minimum bus cycle time of 125 μs makes it ideal for use in high-speed control systems where precise timing is critical.
Precise Actuator Control: It is engineered for applications that demand high accuracy and resolution (16-bit) in controlling actuators. This includes tasks like continuous control of valves, drives, and other process equipment where precise adjustments to voltage or current signals are necessary.
Real-Time Tasks: The module excels in environments where analog signals must be updated with very low latency. This includes applications such as fast closed-loop control in manufacturing, robotics, and other time-critical industrial processes.
Use in Distributed I/O Systems: As a module for the ET 200SP system, it is well-suited for decentralized automation architectures. It can be placed close to the machinery (e.g., in small control boxes near the machine) to control analog devices locally, reducing wiring complexity and improving signal integrity.
